Technical specifications Stainless steel structure Smooth stainless steel plate Dimensions: 800x900x250 mm (WxDxH) Electric power source: 400V~3N Electric power: 14 kW Weight: 79 kg Volume: 0.47 m³
Working top made of AISI 304 with 20/10 thickness and rounded corner. Front, sides and backside made of stainless steel. Stainless steel frame. Table finishing with laser cut in order to guarantee a perfect combination between different tables; they can be very well fasted. On the cooking surface there is a large hole for the draining of the fats in a large container with 2,9 lt capacity situated under the plate. Tube-shaped heating elements with cover made of stainless steel situated directly under the cooking plate. A thermostat sets the temperature of the plate. Working temperature adjustable from 90°C to 300°C. Supplementary safety thermostat with manual resetting. Smooth plate in big dimensions made of a special stainless steel that provides an excellent heat transmission. The mirror finishing of the plate guarantees the non-sticking and a very easy and rapid cleaning following the current norms. The full module item is provided with 2 completely separate plates so that it is possible to cook in 2 different ways and different temperatures. Knobs made of heat-absorbing material with functional screen printing on the boards. A teflon plug is available as an option to cover the hole and cook with some oil.
Technical specifications
Stainless steel structure
Smooth stainless steel plate
Dimensions: 800x900x250 mm (WxDxH)
Electric power source: 400V~3N
Electric power: 14 kW
Weight: 79 kg
Volume: 0.47 m³
Series | 900 Performance |
---|---|
Series | 900 Series |
Power Source | Electric |
Power Source | Electric |
Electric Power [kW] | 14 |
Dimensions [mm] | 800x900x250 |
Weight [kg] | 79 |
Dimensions packaging | 850x950x300 |
